PIR Sensor SY-MV512
Input Voltage: 220-240V AC 50/60Hz
Output Power: Max. 1200W LED 300W
Microwave Frequency: 5.8GHz
Time-Delay: 10sec+3sec to 12min+1min (adjustable)
Distance: Max.15m(radii.), adjustable
Detection angle: 360°
Operating Temperature: -10°C-70℃
Output Power: Max. 1200W LED 300W
Microwave Frequency: 5.8GHz
Time-Delay: 10sec+3sec to 12min+1min (adjustable)
Distance: Max.15m(radii.), adjustable
Detection angle: 360°
Operating Temperature: -10°C-70℃
Technical Specification:
Input Voltage: 220-240V AC 50/60Hz
Output Power: Max. 1200W LED 300W
Microwave Frequency: 5.8GHz
Time-Delay: 10sec+3sec to 12min+1min (adjustable)
Distance: Max.15m(radii.), adjustable
Product Size：Length61.5*Width37*Height25mm
Detection angle: 360°
Operating Temperature: -10°C-70℃
Application Location: Indoor
Installation Location: Wall & Integrated into the light fixture
Application Scenarios:
1. Villas & Houses & Apartments & Hotels & Offices
2. Workshop & Staircases & Corridors
3. Public Toilets & Restrooms & Warehouses
4. Garages & Parking Lot
